G6 Mocap Gloves
- Cutting-edge 15-Axis 4K gyro sensors designed for high angular velocities
- Open kinematics skeleton model authoring system
- Calibrated prop sensor for clubs & rackets
- Live & recorded graphs for nodes, segments & accelerometers
- Export is Visual 3D and csv
- Calibrate, capture & share on iPhone (zero dropped frames)
- Wi-Fi router, Access Point & USB
- 240 FPS with no dropped frames
- Vibrator on hub for PC coms
- GPS integration (optional)
- 2-step 6-second calibrations
- User-configurable calibration
- Open kinematics skeleton model authoring system
- User-set sensor to segment scalable assignments
- Separate body & fingers calibration
- Native host for HTC VIVE
- Plugins for Unreal, Unity, Motive, MotionBuilder & Process Simulate
- Automatic file time-stamps
- UDP triggers start/stop timecode, sync for optical systems
- Open SDK
- Cutting-edge 15-Axis 4K gyro sensors
- 10Hz, 11cm GPS resolution
- Synchronised GPS (optional)
- Patent-pending sensors
- Patented glove calibration jigs
- User changeable sensor PCB
- Live accel data
- 4 glove sizes, same electronics (switch size in 10 minutes)
- Stretch cables -up to 145%
- Cutting-edge 2nd Skin stretch cloth
- Miniature zippers
- Proprietary super-thin stretchy fabric (can leave on for hours)
Synertial’s 9-sensor system utilises 9 IMUs for exceptional quality hand capture.
These Gloves feature sensors on all middle phalanges of the fingers, 3 on the thumb, and 1 on both the palm and the back of the hand. User-configured interpolation and extrapolation provides full-finger data, widely used across animation, industry 4.0 and robotics.
Synertial’s 12-sensor system utlises 12 IMUs for exceptional quality hand capture.
These models include sensors on the proximal and medial phalanges of the fingers, leaving only the distal phalanges for interpolation. The 12-sensor Glove is a robust all-rounder, with applications across multiple industries.
Synertial’s 16-sensor system utlises 16 IMUs for the highest possible data capture.
These models feature sensors on all phalanges of the finger, except the distal phalange of the pinky, and even include a sensor to capture the movement of the 5th metacarpal. This is the optimal glove for medical research and high-fidelity robotics analysis.
The number one option for when accuracy is vital.
Tech Specs
IMU
- Speed – 4000 deg/sec, +/- 16G accelerometers
- Dimensions – 5x13x18 mm
Hub
- Internal storage – unlimited number of files
- Connectivity – WiFi, Bluetooth or wired
- Operating systems – PC, Android, iOS
- Dimensions – 65x65x20 mm
- Modules – GPS
- Power – 3.3V – 5V (operational voltage 3.3V)
Operational
- Capture speed – 200 FPS
- Battery life – 2 hours 45 minutes (unlimited via hotswap)
- Plug-ins – Unity, UE4, MoBu, Siemens PLM, Optitrack Motive
- Carry case – Pelli
- Clothing – Lycra nylon 80% spandex 20%
More Information
Related Products
Created from 25+ years of mocap expertise, all Synertial products utilise innovative cutting-edge IMU technology for outstandingly high capture speeds.
Synertial’s revolutionary 19-sensor system comprises 19 of the highest quality IMUs for full-body capture.
